ALEMADR-MB — Mini Dry Bath Incubator (Heating Only, 0–100°C)
OVERVIEW
The ALEMADR-MB is a compact dry bath incubator (heating only) designed for precise, stable temperature control in routine laboratory workflows.
It supports sample preservation, incubation steps in molecular biology, electrophoresis preparation, and general tube heating where consistent thermal conditions are required.
With ±0.3°C temperature accuracy, visible process display, electronic calibration, and portable DC power, ALEMADR-MB is suitable for benchtop use and mobile/field workflows
(using appropriate 24V/12V adapters). A wide range of interchangeable blocks is available to match common tube formats and strip holders.
Note: Cooling functions (e.g., -10°C operation) are available on the related ALEMADR-MC model, not on ALEMADR-MB.
COLO.SCIENCE KNOWLEDGE
Dry bath incubators: blocks, accuracy and best practice
Learn how to select the right block format, validate temperature accuracy, and optimize incubation steps for PCR prep,
enzyme reactions and sample handling with COLO.Science guides.
TYPICAL APPLICATIONS
- Tube incubation and sample preservation at controlled temperatures
- DNA amplification preparation steps and temperature holds
- Electrophoresis workflow preparation (warming reagents/samples)
- General laboratory heating for microtubes and strips (with matching block)
- Field/mobile lab workflows using DC power options (vehicle adapter)
MODELS & DIMENSIONS
| Model | Function | Temperature range | Dimensions / weight |
|---|---|---|---|
| ALEMADR-MB | Heating only | 0–100°C setting; RT+5–100°C control | 145×113×110 mm / 0.5 kg |
| ALEMADR-MC | Heating + cooling | -10–100°C setting; RT-15–100°C control | 145×113×140 mm / 1.0 kg |
For detailed configuration and options, see catalog (PDF).
TECHNICAL SPECIFICATIONS
| Product models | ALEMADR-MB (heating) / ALEMADR-MC (heating & cooling) |
| Temp. setting range | MB: 0–100°C | MC: -10–100°C |
| Temp. control range | MB: RT+5–100°C | MC: RT-15–100°C |
| Timing range | MB: 1s–999s; 1–999 min; 1–999 h | MC: 1s/1min to 5999 (or ∞) |
| Temp. accuracy | ≤ ±0.3°C (MB / MC) |
| Display accuracy | 0.1°C |
| Heating time | MB: ≤20 min (40→100°C) | MC: ≤20 min (25→100°C)* |
| Cooling features (MC) | Not available on MB; MC supports cooling cycles, AUTO-4°C and multi-point/multi-cycle functions* |
| Voltage / power | MB: DC24V/1.67A, 40W | MC: DC12V/5A, 60W |
| Dimensions / weight | MB: 145×113×110 mm, 0.5 kg | MC: 145×113×140 mm, 1.0 kg |
* Cooling/multi-point/multi-cycle items apply to ALEMADR-MC model.
ACCESSORIES (BLOCKS)
| Accessory | Description |
|---|---|
| PRO4511 | 15 × 2.0 ml tubes |
| PRO4512 | 15 × 1.5 ml tubes |
| PRO4513 | 24 × 0.5 ml tubes |
| PRO4514 | 32 × 0.2 ml (0.2 ml PCR 8-tube strip) |
| PRO6371 | 32 × 0.2 ml (0.2 ml Elisa 8-well strip) |
Custom blocks can be produced to match additional tube formats and holders.
